EuroTech EUM-I/O Addressable EUM-I/O Input/ Output Module is a fully monitored device that permits the interfacing of third-party equipment with the Fire Alarm Control panel using normally open dry contact connections while also providing a changeover output relay to control ancillary equipment. The Green LED will pulse every time the unit is polled by the panel. The Yellow LED will be ON whenever there is a fault condition in the module and finally the Red LED will be ON when there is an alarm condition at the module’s EUM-I/O.
Previous product
Back to products
EuroTech EUC-228 Conventional Fire Alarm Control Panel 28 Zone
AED 2,504.25 VAT included
Next product
EuroTech EUM-I Addressable Input Module
AED 123.90 VAT included
EuroTech EUM-I/O Addressable EUM-I/O Input/ Output Module
AED 141.75 VAT included
Specifications
- Product: Addressable EUM-I/O Input/ Output Module
- Brand: EuroTech
- Model: EUM-I/O
- Supply Voltage: Loop Powered - 17 V to 30 V DC
- LOOP CURRENT - QUIESCENT: I/P: OK 0.46 - FLT OC 0.33 - FLT SC 0.79 mA
- LOOP CURRENT - ALARM LED ILLUMINATED: 2.0 mA + 9.8 mA with Relay Active
- MAX. CABLE SIZE: 2.5 mm²
- MAX. HUMIDITY: 95% RH Non-Condensing
- DIMENSIONS: 100 (D) x 48 (H) mm
- WEIGHT - MODULE: 29 g
Features
- The Addressable EUM-I/O Input/ Output Module is a fully monitored device which permits the interfacing of third party equipment with the Fire Alarm Control panel
- The interface is used to monitor the contacts of an external system which must be interfaced to the Fire Alarm System
- The output relay can be powered from the detection loop (default) or optionally by an external 24 V DC Supply
- The connection to the EUM-I/O is monitored for Fault (open or short circuit) and Alarm conditions
- The factory default setting is for the relay to receive its operating power from the loop
