ETS-CP/R Fire Alarm Control Panel
AED 9,361.24 VAT included
Fire alarm and disabled-refuge control panel for up to 120 outstations with full‑duplex voice and call recording.
Description
The ETS-CP/R fire alarm control panel forms the heart of the fire and disabled-refuge intercom system. Housed in a 304 stainless steel enclosure with IP54 protection, it provides a fault-monitored, full‑duplex voice link between the control room and addressable outstations. The unit integrates a password-protected LCD interface, visual and audible call indications, and automatic call logging with playback for post‑incident review.
The panel operates from a 24 VDC supply with an integral battery charger and backup, ensuring availability during mains failures. Up to 120 addressable outstations can be connected on a 4‑wire radial bus, with as many as four outstations communicating with the control panel at the same time. The design is optimised for fire-safety intercom applications in buildings and critical infrastructure.
Features
- 304 stainless steel housing suited to demanding fire-safety environments.
- IP54 ingress protection as standard, upgradeable to IP65.
- Password-protected LCD interface with clear visual and audible call indications.
- Full‑duplex, fault-monitored voice link between panel and outstations.
- Records all calls with onboard playback for incident analysis.
- Supports up to 120 addressable outstations on a single control panel.
- Up to four outstations can talk to the control panel simultaneously.
- Outstations connect using a 4‑wire radial bus architecture.
- Operates from 24 VDC with integrated battery charger and backup.
- Engineered as part of a dedicated fire-safety intercom system.
Specifications
- Operating voltage: 24 VDC.
- Ringing volume: 85 dB(A) at 1 m.
- Dialling method: PD or DTMF (selectable).
- Surge and lightning protection to ITU‑T K.21 enhanced levels.
- Operating temperature: −40 °C to +65 °C.
- Storage temperature: −40 °C to +75 °C.
- IP rating: IP54 standard; IP65 optional.
- Enclosure size: 530 × 400 × 133 mm (approx.).
- System capacity: up to 120 addressable outstations.
- Simultaneous conversations: up to 4 outstations with the control panel.
