BRONZE Safety Valve 1/2″ 20Bar L3
AED 354.38 VAT included
1/2″ bronze safety valve with 20Bar set pressure, spring-loaded design, and adjustable blowdown. ASME/API 526 compliant.
In stock
Product Code : fs0507666
Brand: Firesupplies
Seller: Fireshop1001Approved by : [woo_pro_badges_extended]
free delivery
Above AED1000 in Dubai
WARRANTY
For 365 days
always authentic
Only Reputed Brands
EASY PAYMENT
Multiple payment options
Description
The 1/2″ bronze safety valve features a spring-loaded mechanism with 20Bar (290PSI) set pressure and adjustable blowdown. Suitable for steam, air, and water applications up to 150°C. Includes threaded connections and lifting lever for manual testing.
Features
- Precise 20Bar set pressure
- Adjustable blowdown (=7%)
- Lifting lever for manual test
- Threaded connections (BSPP)
- ASME/API 526 compliant
- Suitable for steam/water
- Spring-loaded mechanism
- Blowdown adjustment screw
- Temperature range: -20°C to +150°C
Specifications
- Size: 1/2" (DN15)
- Connection: BSPP Female
- Set Pressure: 20Bar (290PSI)
- Max Overpressure: 22Bar
- Blowdown: =7% adjustable
- Body Material: Bronze (CC491K)
- Spring: 316 Stainless Steel
- Seat: Bronze/EPDM
- Standards: ASME I/API 526
- Weight: 0.9kg
