LIFECO Water Flow Switch 2½”
AED 443.63 VAT included
2½” paddle-type water flow switch for fire protection systems, with SPDT contacts and adjustable trip setting. UL/FM approved.
In stock
Product Code : fs0507657
Brand: Lifeco
Seller: Fireshop1001Approved by : [woo_pro_badges_extended]
free delivery
Above AED1000 in Dubai
WARRANTY
For 365 days
always authentic
Only Reputed Brands
EASY PAYMENT
Multiple payment options
Description
The LIFECO 2½” flow switch features a stainless steel paddle, NEMA 4X enclosure, and adjustable flow setting (10-200 GPM). Designed for wet pipe sprinkler systems with 150 PSI working pressure. Includes SPDT switches for alarm and supervisory circuits.
Features
- Adjustable trip setting (10-200 GPM)
- Stainless steel paddle
- NEMA 4X enclosure
- SPDT switches (2)
- UL/FM approved
- Test lever for manual operation
- 150 PSI working pressure
- Corrosion-resistant construction
- Integral delay mechanism
Specifications
- Size: 2½" NPT
- Flow Range: 10-200 GPM (38-757 LPM)
- Pressure Rating: 150 PSI (10.3 bar)
- Electrical Rating: 5A @ 120VAC
- Switch Type: SPDT (2 switches)
- Enclosure: NEMA 4X
- Paddle Material: 316 Stainless Steel
- Body Material: Bronze (C83600)
- Temperature Range: 32°F to 150°F (0°C to 65°C)
- Standards: UL 864, FM 1630
