The HCP-WM incorporates a red LED mounted on the front cover, which can be selected as pulsing/non-pulsing for communications polling and is continuously lit when the the HCP-WM is operated.
The unit is operated by pressing the EN54 compliant non-frangible (plastic) element and, once operated, produces a high level ESP interupt, allowing the control panel to respond very quickly.
A built in test function initiated by the control panel ensures the integrity of the device at all times and the device can be tested by insertion of a test key in the underside of the unit. Two terminal blocks are provided for easy connection to the loop wiring.
The unit is addressed using the TCH-B100 Hand Held Programmer for quick and reliable addressing and an optional glass element is also available.
