Flow-Tek FTV-ACV-100 – Straight Type Deluge Valve – 65 NB(2.5 inch)
AED 6,037.50 VAT included
FLOW TEK ACV FTV 100 DELUGE VALVE are intended to deliver large quantities of water over a large area in a relatively short period of time. The flow tek Deluge Valve is UL approved to 250 psi G. (17.5 bar) in sizes 2½ (65 MM ).
Product Code : fs107777
Seller: Fireshop1001Approved by : [woo_pro_badges_extended]
free delivery
Above AED1000 in Dubai
WARRANTY
For 365 days
always authentic
Only Reputed Brands
EASY PAYMENT
Multiple payment options
Description
FLOW TEK ACV FTV 100 DELUGE VALVE are intended to deliver large quantities of water over a large area in a relatively short period of time. The flow tek Deluge Valve is UL approved to 250 psi G. (17.5 bar) in sizes 2½ (65 MM ). The FLOW AGE deluge Valve is compact, lightweight, and is provided with a preassembled trim all of which minimize the installation time and make it simple and easy. The FLOW AGE Valve opens fast, yet smoothly, preventing water hammer. The FLOW AGE Valve design prevents false tripping and it can be reset by a thumb-activated knob.
Features
- Deluge Valve Model FTV ACV-100
- Fast application of water in spray, pre-action and foam system
- Cast Steel ASTM A216 WCB construction
- Maximum service pressure 17.5 bar ( 250 PSI)
- Horizontal or Vertical installation TRIMS:- WET TRIM, DRY TRIM, ELECTRIC TRIM AVAILABLE
- Diaphragm operated with rubber to metal drip-tight positive sealing
- Easily trimmed for actuation by manual, remote solenoid valve & with wet or dry pilot
- Internal and external surfaces epoxy coated for extra protection
- Flanged connection dimensions to ANSI B 16.5
- Service without removal from the line
Specifications
- Product: Straight Type Deluge Valve
- Brand: Flow-Tek
- Model: FTV ACV-100
- Mounting: Vertical or Horizontal
- Flange Connection: ANSI B 16.5 #150 RF (FF-Optional)
- Finish/Paint: RAL 3000(Red Color)/Fire Red IS Confirm to IS5 Shade 536 to IS 2932
- service pressure: 17.5 bar ( 250 PSI)
- Size: 65 mm (2.5?)- UL LISTED ( CERTIFIED)
- Net Weight: 30 Kg
