SHIELD DI NRV Flange Type 4″ SD NRV300FF-D L.33CM 8 Hole
AED 614.25 VAT included
4″ ductile iron flanged check valve with 8-bolt pattern, 33cm length, and rubber-sealed disc. EN 12334 certified.
In stock
Product Code : fs0507663
Brand: Shield
Seller: Fireshop1001Approved by : [woo_pro_badges_extended]
free delivery
Above AED1000 in Dubai
WARRANTY
For 365 days
always authentic
Only Reputed Brands
EASY PAYMENT
Multiple payment options
Description
The SHIELD SD NRV300FF-D is a ductile iron swing check valve with full-flanged ends (8-hole ANSI 150# pattern). Features nitrile rubber-sealed disc, 33cm body length, and non-slam design. Suitable for water and neutral liquids up to 80°C.
Features
- Full-flanged 8-bolt design
- Non-slam rubber-sealed disc
- Epoxy coated (250µm)
- ANSI 150# pressure rating
- 33cm body length
- EN 12334 certified
- Tested to 30 bar
- Low pressure drop
- Maintenance-free
Specifications
- Size: 4" (DN100)
- Connection: ANSI 150# Flange
- Bolt Holes: 8
- Body Length: 330mm
- Body Material: Ductile Iron (EN-GJS-450)
- Disc Material: Ductile Iron + NBR
- Seat Material: NBR
- Pressure Rating: 20 bar @ 80°C
- Standards: EN 12334, ISO 5752
- Weight: 28kg
