Potter EH-24W is a low profile electronic horn that offers dependable audible output at the lowest current available. The EH24 Series horn offers a continuous or synchronizable temporal three in 2400Hz and mechanical tone, a chime, and whoop tone. All tones are easy for the professional to change in the field by using switches. The EH24 Series is s hiped with the standard 4″ mounting plate which incorporates the popular Super-Slide feature that allows the installer to easily test for supervision. The product also features a locking mechanism that secures the product to the bracket without any screws showing. The EH24 Series also features the patented Checkmate – Instant Voltage Verification feature, which allows the installer to check the voltage drop draw and match it to the blueprint.
Previous product
Back to products
Flametech 6kg Ceiling Mounted Automatic Powder Fire Extinguishers
AED 136.50 VAT included
Next product
Polon-Alfa ROP-63 Conventional Manual Call Point
AED 73.50 VAT included
Potter EH-24W Off-White Faceplate Electronic Horn
AED 367.50 VAT included
Potter EH24 Series is a low profile electronic horn that offers dependable audible output at the lowest current available. The EH24 Series horn offers a continuous or synchronizable temporal three in 2400Hz and mechanical tone, a chime, and whoop tone. All tones are easy for the professional to change in the field by using switches. The EH24 Series is s hiped with the standard 4″ mounting plate which incorporates the popular Super-Slide feature that allows the installer to easily test for supervision.
Specifications
- Product: Electronic Horn
- Brand: Potter
- Model: EH-24W
- Nominal voltage: 24 VDC
- Input terminals: 12 to 18 AWG
Features
- Prewire entire system, install mounting bracket, then install signals
- Synchronize strobe and/or horn with AVSM Control Module
- Switch for continuous or temporal 3 (not available on whoop tone)
- Switch for chime, whoop, mechanical, and 2400 Hz tone
- Documented lower installation and operating costs
- Switch selection for high or low dBA
- Silence horn while strobes remain flashing
- Faceplate available in red or off-white
