Name: Honeywell TC909A1009 Dual Input Module
SKU: fs10195
Price: 850.00 AED
Availability: InStock

Honeywell TC909A1009 Dual Input Module

AED 892.50

Honeywell TC909A1009 Dual Input Module are intended for use in intelligent, 2-wire systems where the individual address of each module is selected using the built-in rotary decade switches.

In stock

Product Code : fs10195 Brand: Honeywell Seller: Fireshop1001 Approved by : [woo_pro_badges_extended]

free delivery

Above AED1000 in Dubai
WARRANTY

For 365 days
always authentic

Only Reputed Brands
EASY PAYMENT

Multiple payment options

Description
Specifications
Features
Questions & Answers
Reviews (0)

Description

Honeywell TC909A1009 Dual Input Module are intended for use in intelligent, 2-wire systems where the individual address of each module is selected using the built-in rotary decade switches. The TC809A provides either a 2-wire or 4-wire fault tolerant initiating circuit for normally open contact fire alarm, supervisory, or security devices. The TC809A has a panel controlled LED indicator.

Specifications

FS90: AE Board.
XLS1000: 3-AADC.
Electrical Ratings: Operating Voltage: 15 to 32 Vdc.
Temperature Ratings: 32øF to 120øF (0øC to 49øC).
Humidity Ratings: 10% to 93%, non-condensing.
EOL Resistance: 47K ohms.
Maximum IDC Wiring Resistance: 40 ohms.
Mounting: Mount directly to a 4 in. (102 mm) standard electrical box with a minimum depth of 2-1/8 in. (54 mm). Surface mounted electrical boxes (SSDSMB500) are available.
Dimensions: 4-1/2 in. (114 mm) high x 4 in. (102 mm) wide x 1-1/4 in. (32 mm) deep.
Approvals: UL 864 listed; FM approved, CSFM listed.
Accessories: SSDSMB500 Electrical Box

Features

Individual addressable input for fire alarm or security devices.
Full analog supervision of circuits.
TC809A have an integral LED to indicate scan, alarm, or activation.
TC809A monitors either two- or four-wire (fault tolerant) initiating device circuits.
