Extech - Thermocouple Calibrator - PRC20

Click to enlarge

Extech – Thermocouple Calibrator – PRC20

Name: Extech - Thermocouple Calibrator - PRC20
SKU: fs0506410
Price: 2477.00 AED
Availability: InStock

See all products from extech

AED 2,477.00 VAT included

Compare

Product Code : fs0506410 Brand: Extech Seller: Fireshop1001Approved by : [woo_pro_badges_extended]

free delivery
Above AED1000 in Dubai
WARRANTY
For 365 days
always authentic
Only Reputed Brands
EASY PAYMENT
Multiple payment options

Description

The PRC20 sources and measures eight thermocouple type devices (J, K, T, E, C, R, S and N) and provides precision output displayed as Centigrade/Fahrenheit or mV. It has five user adjustable calibration presets and a Type K temperature range of -58 to 2498 degrees F (-50 to 1370 degrees C). The PRC20 is suitable for Lab and field calibration, Engineering research and design, Manufacturing and test engineering, Temperature control process troubleshooting and HVAC applications. Comes with thermocouple calibration cable with subminiature connectors, standard calibration cable with subminiature connectors, 100V-240V AC universal adaptor with four plugs, six 1.5-volt AA batteries, hard case, and user manual.

Features

Source and measure 8 thermocouple type devices (J, K, T, E, C, R, S and N)
CJC - Cold Junction Compensation function
Up to five user adjustable calibration presets
Palm-sized double molded housing and large dot-matrix digital backlit LCD with thermocouple type indication
High accuracy calibration function simulates precision thermocouple outputs for use in calibrating thermometers, transmitters, controllers or recorders
Displays output in terms of millivolts or temperature based on thermocouple tables
Mini thermocouple connector
Large battery bank for extended work cycle
External power adapter for continuous work cycle
Complete with calibration cables, 100V-240V AC universal adaptor with 4 plugs, 6 AA batteries, and hard carrying case

Specifications

Brand: Tekneka
Product: Thermocouple Calibrator
Model: PRC20
Voltage: -10.00mV to +60.00mV
Resolution: 0.1° (up to 999.9) or 1° (over 999.9°) for J, K, T, E ; 1° for R, N; 0.5° for C, S
Input Impedance: 10M?
Sampling Time: 4 times/second
